Machinery equipment

Vertical Machining Center MAS MCV 2220

Vertical Machining Center MAS MCV 2220

A range of MCV machines is built on a C-shaped support frame. The layout and shape of the machine frame castings is optimized for high stiffness and stability. The linear guide application in all linear axes guarantees the required precision and dynamics of machining. High-performance machining is ensured by the application of high-speed spindles and rapid feed rates. High stiffness of the machine frame allows for both power machining and very precise machining of complex parts.

- type of CNC machining: power / high speed
- workspace: 2400 x 850 mm1500 x 670 mm
- maximum workpiece weight: 3500 kg
- axis travel X x Y x Z: 2200 x 860 x 860 mm
- maximum speed: 8000 rpm
- number of tools: 40

Vertical Machining Center MAS MCV 1270

Vertical Machining Center MAS MCV 1270

A range of MCV machines is built on a C-shaped support frame. The layout and shape of the machine frame castings is optimized for high stiffness and stability. The linear guide application in all linear axes guarantees the required precision and dynamics of machining. High-performance machining is ensured by the application of high-speed spindles and rapid feed rates. High stiffness of the machine frame allows for both power machining and very precise machining of complex parts.

- type of CNC machining: power / high speed
- workspace: 1500 x 670 mm
- maximum workpiece weight: 1200 kg
- axis travel X x Y x Z: 1270 x 610 x 720 mm
- maximum speed: 8000 rpm
- number of tools: 24
- tool change time: 5 s

Vertical Machining Center MAS MCV 750

Vertical Machining Center MAS MCV 750

A range of MCV machines is built on a C-shaped support frame. The layout and shape of the machine frame castings is optimized for high stiffness and stability. The linear guide application in all linear axes guarantees the required precision and dynamics of machining. High-performance machining is ensured by the application of high-speed spindles and rapid feed rates. High stiffness of the machine frame allows for both power machining and very precise machining of complex parts.

- type of CNC machining: power / high speed
- workspace: 1000 x 640 mm
- maximum workpiece weight: 650 kg
- axis travel X x Y x Z: 750 x 500 x 500 mm
- maximum speed: 12000 rpm
- number of tools: 24
- tool change time: 4 s

Bridge crane Konecranes CXTS5t

Bridge crane Konecranes CXTS5t

The CXT rope hoist crane is an indispensable helper in an industrial plant. It is a medium-duty hall crane with a lifting capacity of 5 tons and a span of 10.5 m.

- span: 10,5 m
- crane capacity (SWL): 5000 kg
- number of main hoists: 2
- load capacity of the hoist: 5000 kg
- stroke height: 3,6 m

Bernardo BSG 3060 PLC surface grinding machine with digital measuring

Bernardo BSG 3060 PLC surface grinding machine with digital measuring

The Bernardo BSG series surface grinders have a solid construction and, as standard, are equipped with an automatic vertical feed and a magnetic clamping plate. All major components such as the stand, base and apron are made of high-quality grey cast iron. Due to the extensive standard equipment, these models provide an optimal and cost-effective alternative for repairs and production of moulds, tools.

- Work table size: 305 x 635 mm
- Electromagnetic clamping plate: 300 x 600 mm
- Max. feed - longitudinal: 765 mm
- Max. feed - transverse: 340 mm
- Max. distance of the spindle centre from the table surface: 580 mm
- Max. workpiece weight: 270 kg
- Grinding wheel dimensions: 350 x 40 x 127 mm
- Spindle speed: 1 450 U/min

Bernardo SMART 410 x 1000 universal lathe with digital measuring

Bernardo SMART 410 x 1000 universal lathe with digital measuring

This Smart 410 lathe is designed for small to medium-size turning works. The basic equipment of the lathe (included in the delivery) contains important accessories for universal use. The model is supplied with digital measuring in all three axes.

- Engine power: 3 300 / 4 500 W
- Distance between centres: 1 000 mm
- Swing over bed: 410 mm
- Swing over gap: 580 mm
- Swing over cross slide: 255 mm
- Speed range: 45 - 1 800 U/min

Bernardo SB 4 Sandblasting machine

Bernardo SB 4 Sandblasting machine

The sandblasting machine is suitable for blasting larger objects - roughening, smoothing, unification, renovation of worn surfaces, removal of rust, dross, paint, etc.

- Workspace: 1 110 x 820 x 810 mm
- Useable grit size (recommended): 0.149 - 0.250 mm
- Hopper capacity: 148 l
- Air flow: 680 l/min
- Air pressure (recommended): 8,6 bar

Column Drill VS 32B

Column Drill VS 32B

VS 32 B Pillar Drill is designed for drilling, reaming and cutting of reversing head threads in piece and series production. The headstock and bracket are vertically adjustable and 360 degrees rotatable around the column. The machine is equipped with 15 speeds, 4 degrees of machine feeds and with switching on/off the automatic feed clutch. The automatic clutch provides automatic feed shut off, which is determined when adjusting the machine, and is activated when the tool is excessively blunt or bent.

- drill diameter in steel: 32 mm
- drill depth: 200 mm
- speed range: 56 – 2240 rpm
- max. axial pressure on spindle: 8000 N

Gravity Band Saw Pilous ARG 220 plus

Gravity Band Saw Pilous ARG 220 plus

The 27 x 0.9 mm industrial saw band is produced in many variants and allows the division of a wide range of materials, including stainless steel or tool steels. The saw band arm is lifted by hand, the saw feed is performed by the weight of the arm with the possibility of fine and smooth control by the oil damper throttle valve. When the cut is complete, the saw band drive will automatically switch off. For easy lifting of the arm, the machine is equipped with adjustable tension springs, enabling to adjust the optimum force required to raise the arm according to the nature of the cut material. The vice system also contributes to the versatility allowing a two-sided, continuous adjustment of the cutting angle in the range of 60 ° on the right and 45 ° on the left. The rotary table rotates simultaneously with the saw band. This prevents cutting the saw band into the into the loading surface of the vice.

- cutting method: gravity
- working height of the vice: 900 mm
- band speed: 40/80 m/min
- setting the angle of cut: from -45° to 60°

EDM Wire-cutting Machine FANUC Robocut Alpha C600iB

EDM Wire-cutting Machine FANUC Robocut Alpha C600iB

A fast and highly accurate universal wire cutter built on the most reliable mechanical structure of the compound table. Preloaded linear guides and very precise ball screws fully covered in fat fill provide the best solution in the long run and contribute to the precision of production. The machine is designed for very low maintenance requirements and an incredibly long service life. This saves production time, reduces production costs and ensures the highest cutting accuracy. EDM wire-cutting machine FANUC Robocut Alpha C600iB is designed and manufactured exclusively in Japan, which significantly contributes to machine quality and subsequent production.

- EDM cut method: underwater / with rinse
- maximum workpiece dimensions: 1050 x 820 x 300 mm
- maximum workpiece weight: 1000 kg
- axis travel X x Y x Z: 600 x 400 x 310 mm
- cutting wire diameter: 0,1 to 0,3 mm
- minimum table motion: 0,0001 mm

EDM Drill SY-2030

EDM Drill SY-2030

The electro-erosive drill SY-2030 achieves high performance especially when drilling hardened steels and cemented carbides with a hole diameter of 0.2-3 mm. The spindle is assembled from two blocks, the top and bottom cables of cemented carbides with very low wear, which brings cost savings in production. High intensity of rinsing when drilling, a spindle driven by a high-speed servomotor and positioning accuracy, depth-to-hole ratio of 200: 1, simple and clear operation - all this ensures precise machining results. The machine is suitable for drilling start-holes for wire cutters, mold making and can be simply used for drilling into molded surfaces.

- EDM drilling method: under rinsing
- table size: 210 x 460 mm
- axis travel X x Y x Z: 300 x 200 x 350 mm
- electrode diameter: 0,2 - 3 mm
- measuring accuracy: 0,005 mm

EDM Sinking Machine PENTA 433GS

EDM Sinking Machine PENTA 433GS

It is electro-erosive sinking machine of Czech production, with the BECKHOFF branded German control system and with digital AC servomotors. A complete solution from one manufacturer facilitates service, guarantees perfect compatibility and fast response. The machine is characterized by a solid construction, precise linear guide and ball screws. The new range of these sinking machines boasts the lowest operating costs in its class. This is undoubtedly supported by improvement in automation, unattended operation, perfect remote access to the machine via LAN and the Internet.

- EDM sinking method: underwater
- working tank X x Y x Z: 1000 × 550 × 320 mm
- clamping table: 700 × 350 mm
- maximum workpiece weight: 700 kg
- axis travel X x Y x Z: 400 × 300 × 300 mm
- distance table - quill (min - max): 130 - 430 mm

CNC lathe

CNC lathe

(we prepare)

5-axis vertical machining center

5-axis vertical machining center

(we prepare)

3D measuring and scanning system

3D measuring and scanning system

(we prepare)
